Cavo 1E1C305A — Accessories | Italsensor
Accessorio

Cavo 1E1C305A

Oil-resistant, flame-retardant, shielded (>80%) pre-wired cable in special PVC. External diameter: 6.20 mm max. Color: Black. Standards: CEI 20-11, VDE 0295, EU Directive RoHS. N° 5 conductors section 0.35: red, black, green, yellow, blue. Bending radius: 10 times the external diameter. Temperature: -15°C / +80°C.

CERoHSCEI 20-11

Technical Specifications

ParameterValue
Protection Rating-
Housing MaterialPVC speciale resistente olio
Operating Temperature-15°C / +80°C

Download Center

CE Declaration
